CCNA Training hari Keenam EIGRP basic dan Pengenalan GNS3

A.Pengenalan

Hari keenam Workshop Cisco di BLC telkom Klaten,pada hari ini adalah hari terakhir workshop,materi yang diberikan oleh mas Ardes adalah Basic EIGRP,konfigurasi GNS3 dan Foto Bersama di hari terakhir workshop.


B.Latar Belakang

Workshop Training Cisco selama 1 minggu di BLC telkom Klaten.

C.Alat dan Bahan
1.Laptop
2.GNS 3
3.Kabel Lan


D.Pelaksanaan dan Kegiatan

Materi EIGRP Basic
lllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllll
Buat Topologi :


Konfigurasi IP address dan Loopbacknya di R1,R2 dan R3.

R1(config)#int Lo1
R1(config-if)#ip address 1.1.1.1 255.255.255.0
R1(config-if)#no shut
R1(config-if)#exit
R1(config)#interface Ethernet0/0
R1(config-if)#ip address 192.168.1.1 255.255.255.0
R1(config-if)#no shut
R1(config-if)#exit
R1(config)#interface Ethernet0/1
R1(config-if)#ip address 172.16.1.1 255.255.255.0
R1(config-if)#no shut
R1(config-if)#exit

R2(config)#int Lo2
R2(config-if)#ip address 2.2.2.2 255.255.255.0
R2(config-if)#no shut
R2(config-if)#exit
R2(config)#interface Ethernet0/0
R2(config-if)#ip address 192.168.1.2 255.255.255.0
R2(config-if)#no shut
R2(config-if)#exit
R2(config)#interface Ethernet0/2
R2(config-if)#ip address 172.16.1.2 255.255.255.0
R2(config-if)#no shut
R2(config-if)#exit

R3(config)#int Lo3
R3(config-if)#ip address 3.3.3.3 255.255.255.0
R3(config-if)#no shut
R3(config-if)#exit
R3(config)#interface Ethernet0/3
R3(config-if)#ip address 172.16.1.3 255.255.255.0
R3(config-if)#no shut
R3(config-if)#exit


R1#sh ip int br
R2#sh ip int br
R3#sh ip int br


Konfigurasi EIGRP

R1(config)#router eigrp 10
R1(config-router)#no auto-summary
R1(config)#network 1.1.1.0
R1(config)#network 172.16.1.0
R1(config)#network 192.168.1.0

R2(config)#router eigrp 10
R2(config-router)#no auto-summary
R2(config)#network 2.2.2.0
R2(config)#network 172.16.1.0
R2(config)#network 192.168.2.0

R3(config)#router eigrp 10
R3(config-router)#no auto-summary
R3(config)#network 3.3.3.0
R3(config)#network 172.16.1.0
R3(config)#network 192.168.3.0

2.Pengertian GNS3
lllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllllll

Gns3 adalah sebuah software simulasi jaringan komputer yang berbasis GUI sama seperti Cisco Packet Tracer tetapi GNS lebih komplekskarena menggunakan operating system asli dari perangkat jaringan seperti cisco dan juniper.Cara Install GNS3 KLIK DISINI

E.Dokumentasi

F.Hasil dan Kesimpulan

Konfigurasi CCNP diatas merupakan konfigurasi antara router ke router lainnya dengan hanya menggunakan 1 switch.


G.Referensi : ebook Lab CCNP
